Outdoor Lithium Batteries

Solar Energy Storage Lithium Battery (12V16Ah)

Lithium iron phosphate cell, safe and stable, long cycle life;

Built-in BMS protection system + inverter module, multiple safety protections;

Integrated injection molded hand-held shell, equipped with LCD display;

Multi-interface output: AC, 12V DC, USB2.0, USB3.0, support 15V solar input;

Independent key control for DC and AC, simple and intuitive operation;

Product Certification

Product Specifications

Product No.
Hd-CN-12-007
Battery Specification
21700, 3.2V / 4S4P / 12V16Ah
Product Dimension
240mm × 195mm × 120mm
Battery Weight
Approx. 3kg
Nominal Voltage
12V
Nominal Capacity
16Ah
Charging Temperature
0℃ ~ +55℃
Discharging Temperature
-20℃ ~ +60℃
Charging Voltage
14.6V
Charging Current
Standard 0.5C (8A), maximum support 16A
Instant Discharge Current
32A
Discharge Cut-off Voltage
10V
Temperature Protection
BMS multi-point NTC temperature control; high temperature protection ≥60℃, low temperature protection ≤0℃
Battery Housing
Engineering plastic injection molded housing
Communication
None
Application Fields
Outdoor camping, household emergency backup power supply, field survey, small photovoltaic energy storage, vehicle temporary power supply
